| Technical parameter | |
| Turntable structure: | Roll: O-type; |
| Pitch: O-type; | |
| Heading: U-type | |
| Rotation angle range: | ±120° (three-axis) |
| Position accuracy: | <±30" (three-axis) |
| Angular velocity range: | Roll: 0.01~120°/s; |
| Pitch: 0.01~120°/s; | |
| Heading: 0.01~120°/s; | |
| Rate accuracy: | When w<1/s, the velocity error is ≤0.1/s; |
| When w≥1/s, the velocity error is ≤1.5/s; | |
| Maximum angular acceleration: | Roll: ≥300°/s²; |
| Pitch: ≥200°/s²; | |
| Heading: ≥200°/s²; | |
| Load Weight: | not less than 45kg; |
| Hollow size of load: | not less than 6230mm |
| Platform weight: | 287kg |
| Overall dimensions: | 600×785.5×1410mm |
