Technical Parameters
|
|
| Indicator Name | Indicator Parameters |
| Structure | Double axis |
| Rate Range | 0.01°/s ~ 50°/s |
| Rate Stability | 0.05°/s (1 second average) |
| Position Accuracy of Two-axis Rotation Mechanism | ±1′ (60″) |
| Locking Scheme | Mechanical lock (electric control), unit set (zero, horizontal position is 0) lock |
| Angle Range | Maximum rotation angle greater than 270° |
| Time Synchronization | IMU sends the time synchronization signal to the dual-axis rotation mechanism, and supports the dual-axis rotation mechanism and the IMU data synchronization output |
| Double-axis Transposition Mechanism Installation | Design the base for mechanism mounting |
| Weight | 2-3 kg |
| Volume Range | Not larger than 150 mm × 150 mm × 150 mm |
| Communication Method | RS232/RS422 |
