| No. | Indicator Item | Technical Parameters |
|---|---|---|
| 1 | Rotation range | Pitch: +30° ~ -30° Heading: +50° ~ -50° |
| 2 | Maximum angular velocity | Pitch: 180°/s Heading: 180°/s |
| 3 | Angular acceleration | Better than 0.01 ~ 100°/s² |
| 4 | Angular position accuracy | ≤ ±0.002° |
| 5 | Angular position resolution | 0.001° |
| 6 | Inner two axle load weight | Not less than 130kg, can be installed with the sensor to be tested |
| 7 | External two axle load weight | Not less than 120kg, should be able to install the target simulator |
| 8 | Turntable dimensions | Approximately 4.95m × 4.095m × 5.119m (L×W×H) |
| 9 | Total weight of turntable | About 22t |
