| Technical Parameter | |
|---|---|
| Table size | ≥15cm |
| Load weight | maximum 4kg |
| Speed | inner ring ≥2000°/s, outer ring ≥500°/s |
| Position resolution | 0.0001° |
| Position accuracy | 5" |
| Position repeatability | 5" |
| Angular velocity resolution | 0.001°/s |
| Inner ring angular position error at constant speed | 100dps, 200dps, 300dps, 400dps, 500dps±0.0015°; 1000dps±0.002°; 2000 dps±0.0023°; |
